Synchron USB Charger Panasonic CGAS002 with LCD

PATONA Synchron USB Charger f. Panasonic CGAS002 with LCD

The exclusive PATONA Synchron USB Charger f. Panasonic CGAS002 is capable to charge a battery and another device over the USB-Output at the same time.
The LCD Display shows the current charge level of the battery. It doesn’t matter if it is connected to a power source or not.
It is possible to use a 100-240V wall socket, 12-24V Car charger or 5V Micro-USB to power the device.
The build in Microchip protects the battery from damage due to overheating and overload.

Compatible to following batteries:
Panasonic CGAS002, CGA-S002, CGAS002A, CGA-S002A, CGAS002E, CGA-S002E, CGAS006E, CGA-S006E, CGRS002, CGR-S002, CGRS002A, CGR-S002A, CGRS006, CGR-S006, DMWBM7, DMW-BM7

Compatible model number:
Panasonic
Lumix FZ5, DMCFZ 8, DMC-FZ 8, DMCFZ1 FZ1B, DMC-FZ1/ FZ1B, DMCFZ10, DMC-FZ10, DMCFZ15, DMC-FZ15, DMCFZ2, DMC-FZ2, DMCFZ20, DMC-FZ20, DMCFZ3, DMC-FZ3, DMCFZ30BB , DMC-FZ30BB , DMCFZ30EG, DMC-FZ30EG, DMCFZ30EGK , DMC-FZ30EG-K , DMCFZ30EGS , DMC-FZ30EG-S , DMCFZ30K , DMC-FZ30-K , DMCFZ30S, DMC-FZ30-S, DMCFZ4 FZ5, DMC-FZ4 FZ5, DMCFZ50 , DMC-FZ50 , DMCFZ50EG , DMC-FZ50EG , DMCFZ50EGK, DMC-FZ50EG-K, DMCFZ50EGS , DMC-FZ50EG-S , DMCFZ7BB , DMC-FZ7BB , DMCFZ7BS , DMC-FZ7BS , DMCFZ7EGK, DMC-FZ7EG-K, DMCFZ7EGS , DMC-FZ7EG-S , DMCFZ7K , DMC-FZ7-K , FX1, FX5

Technical Data:
Input:
AC 100V-240V 50/60Hz400mA (max)
DC 12-24V 1300mA (min)
Micro USB 5V 1000mA

Output:
DC 4,2V / 8,4V 800mA
USB Output: DC 5V 1000mA

Attention: As a safety measure the USB-Output will automatically deactivated if Micro-USB is used as input to power the device.

Pictures are only for illustration purposes! Delivery may vary.
